PAPAGO Meteo RS: Industrial Weather Station Main Base with RS485 ModBus – PGO_METEO_R_1
Measures the level of CO2, temperature, humidity, dew point, atmospheric pressure, wind speed, and wind direction. PAPAGO is a family of devices with a uniform appearance and communication capabilities. It allows combining communication interfaces on one side and measurement sensors (inputs) on the other.
PAPAGO Meteo RS: Industrial Weather Station Main Base with RS485 ModBus – PGO_METEO_R_1
Measures the level of CO2, temperature, humidity, dew point, atmospheric pressure, wind speed, and wind direction. PAPAGO is a family of devices with a uniform appearance and communication capabilities. It allows combining communication interfaces on one side and measurement sensors (inputs) on the other.
- Modbus (RTU and Plus)
- RS485
- Serial
- Papouch Measurement
PAPAGO Meteo RS measures the level of CO2, temperature, humidity, dew point, atmospheric pressure, wind speed, and wind direction. PAPAGO is a family of devices with a uniform appearance and communication capabilities. It allows combining communication interfaces on one side and measurement sensors (inputs) on the other.
The main base must be supplemented with sensors according to the application. We strongly recommend using surge protection.
Sensors
It is possible to connect up to three of the following sensors simultaneously (to connectors A, B, and C):
(sensors not included)
- Wind speed and direction sensor: Measures wind speed (0.5 to 89 m/s) and wind direction (± 3°) (connector C only)
- Carbon dioxide CO2 concentration sensor: Measures in the range of 0 to 2000 ppm with excellent accuracy of ± 25 ppm. (NDIR optical sensor, connector A or B)
- Combined sensor: Measures temperature (-40 to +125 °C), humidity (0 to 100%), and dew point (connector A or B)
- Combined sensor: atmospheric pressure (50 to 110 kPa), temperature (-40 to +125 °C), humidity 0 to 10 %, (connector A or B)
- Temperature sensor: Measures temperature (-55 to +125 °C) (connector A or B)
Features
- Tracking of meteorological values and processing
- Measurement of CO2 levels, wind speed, and wind direction in industry
- Expansion of PLCs: addition of meteorological values
- Measurement for the HACCP system
- Detection of wind speed for automatic retraction of various blinds
- RS485 interface with Modbus RTU protocol.
- Wide supply voltage input from 11 to 58 V DC.
- Typical current consumption: 26 mA at 24 V
- Measures (a) external thermometer, (b) combined sensor with temperature and humidity, (c) combined sensor for pressure, temperature, and humidity, (d) CO2 level concentration, or (e) wind speed/direction sensor (sensors sold separately).
- Robust and elegant metal chassis that can be mounted on a DIN rail. The connections are inscribed on the chassis for easy wiring. LED indicators show all imports
